So I noticed my truck running a bit tough, and sounding funny, like I dropped a Flowmaster muffler in place of the stocker. Admittedly the sound is pretty cool.
And then the code got thrown....
Out comes the SCT XCal2 and I check the code to find a 0016 and look it up, sure enough, it is Variable Cam Timing Solenoid bank1....
Now that is no shock, the 5.4L 3V Ford Triton V8 is somewhat known for VCT issues. So I order BOTH solenoids, hey if one is going, the other isn't far behind right?
And then realize the solenoids doin't come with the little metal / rubber grommets that seal the solenoid to the valve cover, so I make a mad dash to the Ford dealer to grab the grommets, and then back home to follow the instructions in the manual...
In one of the early on steps after disconnecting the battery, and wiring harness connector for the solenoid, you are supposed to simply and easily pull the grommet from the valve cover....
NOT such a simple task...
As I write, the grommet is not leaking, but it IS pried up about 1/2 way and waiting for me to climb my happy butt back up into that engine compartment to finish yanking that dumb thing out of there...
It is repair jobs like this, that should be oh so simple that make me wonder... Do the manufacturers intentionally hire sadistic engineers or is this engineering choices driven by the accounting department?
Either way, it is making my life tougher than it needs to be...
I will take another whack at it tomorrow, maybe I will have more luck!
12 December, 2014
25 October, 2014
Building my own Camera Jib / Crane
In my research on how to improve my videos, one of the items that keeps cropping up is a camera jib / crane which will allow for smooth pan / raise / lower of perspective, etc...
There are tons of DIY howtos on Youtube for building various designs of jibs, and after a good deal of research, I had several requirements which were.
#1. Minimum top camera elevation of 8' while mounted on the tripod.
#2. Breaks down to an easily transportable size, no harder to transport than the tripod itself.
#3. Easy to build.
#4. Reasonable cost.
#5. Adjustable length.
#6. Fixed level, and rotating level capability.
After reviewing a LARGE number of camera jib builds, I came across one that while not perfect, for the most part suits my needs.
The video from the gentleman that built the inspiration jib is here...
There are several build quality issues, and minor design flaws, or at least choices I disagree with that I will be doing differently...
Yes, I am building one...
My first steps were today. So far I have...
#1. Done the shopping for items I need to build this. The extension poles I got came from Home Depot, they were on clearance so I got lucky.
#2. The casters I got were close, but not dead on, and I am NOT using 1x4 stock, but rather scrap 3/4" plywood, and 2x6 that I will be cutting rabbets into. I have removed the wheels from the small casters courtesy of my Dremel and a cutoff wheel. The large caster axle is simply a nut and bolt arrangement so I simply unbolted the wheel...
#3. I have the plug pieces for the PVC / small casters and the platform cut and glued up in clamps right now. Unlike the gent who made the inspiration piece, I have sanded my parts, and gotten them smooth prior to getting them in glue, and I am NOT adding screws to it. However I WILL be using a set screw to help retain the plugs a bit better. I used a 1.5" hole saw to cut the plug. Yes I have a hole in the middle, I just don't care that much....
I was unable to source up the yolk parts however I am figuring on fabricating a suitable yolk for each side. Most likely will be made from either aluminum, or steel. Depends on what I can source up from my scrap buckets... I think I have some aluminum. Either way, I will be connecting to the small end of the poles using rivets, which means no cutting of the poles themselves.
For the weight / counterbalance issue, I am thinking about adapting the aluminum extrustion to PVC, and then some small athletic lifting weights held in with some sort of retained cap.... Not sure how to explain this, Hopefully in the next few posts I can get it clear...
There are tons of DIY howtos on Youtube for building various designs of jibs, and after a good deal of research, I had several requirements which were.
#1. Minimum top camera elevation of 8' while mounted on the tripod.
#2. Breaks down to an easily transportable size, no harder to transport than the tripod itself.
#3. Easy to build.
#4. Reasonable cost.
#5. Adjustable length.
#6. Fixed level, and rotating level capability.
After reviewing a LARGE number of camera jib builds, I came across one that while not perfect, for the most part suits my needs.
The video from the gentleman that built the inspiration jib is here...
There are several build quality issues, and minor design flaws, or at least choices I disagree with that I will be doing differently...
Yes, I am building one...
My first steps were today. So far I have...
#1. Done the shopping for items I need to build this. The extension poles I got came from Home Depot, they were on clearance so I got lucky.
#2. The casters I got were close, but not dead on, and I am NOT using 1x4 stock, but rather scrap 3/4" plywood, and 2x6 that I will be cutting rabbets into. I have removed the wheels from the small casters courtesy of my Dremel and a cutoff wheel. The large caster axle is simply a nut and bolt arrangement so I simply unbolted the wheel...
#3. I have the plug pieces for the PVC / small casters and the platform cut and glued up in clamps right now. Unlike the gent who made the inspiration piece, I have sanded my parts, and gotten them smooth prior to getting them in glue, and I am NOT adding screws to it. However I WILL be using a set screw to help retain the plugs a bit better. I used a 1.5" hole saw to cut the plug. Yes I have a hole in the middle, I just don't care that much....
I was unable to source up the yolk parts however I am figuring on fabricating a suitable yolk for each side. Most likely will be made from either aluminum, or steel. Depends on what I can source up from my scrap buckets... I think I have some aluminum. Either way, I will be connecting to the small end of the poles using rivets, which means no cutting of the poles themselves.
For the weight / counterbalance issue, I am thinking about adapting the aluminum extrustion to PVC, and then some small athletic lifting weights held in with some sort of retained cap.... Not sure how to explain this, Hopefully in the next few posts I can get it clear...
11 October, 2014
Roller Fairlead LIcense Plate Bracket Installation and Demo
This is the second related video to this. Actually a modification of the first. I have added a functional demonstration on to the end. Sorry about the foggy video, It's been raining and it was pretty much impossible to keep the camera lens from fogging up....
I sincerely hope my blog posts, and videos are helping you folks, and look forward to your feedback.
If you like what I am doing here and would like to support Daves Workshop, please feel free to make a donation using the Donate Now button on the bottom of the page. Thanks!
I sincerely hope my blog posts, and videos are helping you folks, and look forward to your feedback.
If you like what I am doing here and would like to support Daves Workshop, please feel free to make a donation using the Donate Now button on the bottom of the page. Thanks!
EZ Flip License Plate Bracket Installation.
Hopefully this is understandable. My truck has a winch mounted in front of the OE license plate holder. The clip on type license plate holders are just begging for plate theft, so I opted to install a permanent flip up type license plate bracket onto the Roller Fairlead. I am going through the process of installing and figuring it out as I am shooting the video, I sped through the more mundane parts, and omitted the final installation as it is simmply the reverse of removal, I also omitted using a dremel to elongate the mount holes and turn them into slots. I could do a video on that process if you'd like, but I figure folks kind of know how to do that... Let me know if you need to see it done!
09 October, 2014
Roller fairlead license plate mount installation.http://astore.amazon.com/davework-20/detail/B00FH5KKM6
For my readers that own 4x4, or service trucks of some sort, and are equipped with a front mounted winch, I have found a workable solution to replace jamming your front license plate up on the dashboard, or using bailing wire to hold it to the grille...
On my 2004 Ford F150, I have an Engo E9000 winch installed on a Go Rhino brush guard / winch mount. It looks great, and pulls even better. But living and driving in a state that requires both a front and a rear license plate on my vehicle required some serious digging...
At first I tried the Smittybuilt roller fairlead license plate bracket. Simply put, Don't bother. The weight of the unit itself simply slides down the rollers, there is great lateral control and hold, just not vertical, and no permanent mount of any sort, just grab and pull and off comes your license plate for any thief that wants an easy plate to steal...
I found out the hard way how easy it was to lose my front plate. Earlier this week I got a call from Officer Muir of the Friendswood Texas Police department asking if I drove a beige Ford truck...
Fearing my truck had been stolen, I shakily responded yes I do... Is there a problem?
He kindly informed me that he believed he might have my license plate, it was found in my church parking lot...
I guess I parked too close to the bushes on Sunday.
A quick order of the EZ Flip License Plate bracket and a quick installation and I now have the problem permanently fixed...
I should have noted the fit notes. My Engo E9000 appears to be nothing more than a rebadged Smittybuilt 9K, and the fairlead looks the same. The EZ Flip says it does NOT fit Smittybuilt... I found out the hard way, they are right...
Some quick grinding with my rotary tool and the holes were elongated sufficiently to securely hold the bracket, and off to the races I went...
I have a suggestion to the folks that make the EZ Flip. Why don't you set your laser cutter to make the mount holes elongated such that it will fit Smittybuilt, and Warn style roller fairleads? It might take an extra half a second in manufacturing, but would open up a MUCH larger market for your product!
Bypassing that issue, the install went very smoothly.
Step #1. Gather tools needed. These include a Phillips head screwdriver, Outward opening spring clip pliers, a 1/4" socket set with extension and U joint, and a set of metric allen wrenches.
Step #2. Unbo the unit, and remove the protective plastic from the metal surfaces.
Step #3. Using the small flat head screws and locknuts, attach the plastic clips to the metal frame.
Step #4. If your fairlead is installed correctly, the spring clips will be on the BOTTOM of the roller fairlead. Careful remove the clips and pins leaving the rollers in place.
Step #5. Assemble the license plate to the frame. Top of plate goes toward the hinge.
Step #6. With license plate facing away from you, line up the mount holes in the hinge ears to the holes in the fairlead, and reinstall pins.
Step #7. Reinstall spring clips. If you have them available, now might be a good time to get new ones put on.
If you did everything correctly you should be able to swing the plate down into position, and click it on to your rollers to secure it. Pulling in a rotating motion from the bottom of the plate unhooks it and the spring swings it up and out of the way to allow for winch use...
This thing is just so brilliant, and necessary for those of us in 2 plate states to avoid tickets that it ought to be included with the winch, or at least the fairlead... Like I said, this thing is brilliant!
Speaking of brilliant, there is ONE configuration I can think of where this will NOT work... On my fairlead there are holes right behind the pin holes to mount off road lights. If those lights were mounted, they would interfere with the operation of the plate bracket. Long story short, won't work, at least not well...
Now that I am done, I have a solid, secure, and somewhat good looking plate mount that keeps me from getting the attention of my local police department.
All things considered, a win win for me!
On my 2004 Ford F150, I have an Engo E9000 winch installed on a Go Rhino brush guard / winch mount. It looks great, and pulls even better. But living and driving in a state that requires both a front and a rear license plate on my vehicle required some serious digging...
At first I tried the Smittybuilt roller fairlead license plate bracket. Simply put, Don't bother. The weight of the unit itself simply slides down the rollers, there is great lateral control and hold, just not vertical, and no permanent mount of any sort, just grab and pull and off comes your license plate for any thief that wants an easy plate to steal...
I found out the hard way how easy it was to lose my front plate. Earlier this week I got a call from Officer Muir of the Friendswood Texas Police department asking if I drove a beige Ford truck...
Fearing my truck had been stolen, I shakily responded yes I do... Is there a problem?
He kindly informed me that he believed he might have my license plate, it was found in my church parking lot...
I guess I parked too close to the bushes on Sunday.
A quick order of the EZ Flip License Plate bracket and a quick installation and I now have the problem permanently fixed...
I should have noted the fit notes. My Engo E9000 appears to be nothing more than a rebadged Smittybuilt 9K, and the fairlead looks the same. The EZ Flip says it does NOT fit Smittybuilt... I found out the hard way, they are right...
Some quick grinding with my rotary tool and the holes were elongated sufficiently to securely hold the bracket, and off to the races I went...
I have a suggestion to the folks that make the EZ Flip. Why don't you set your laser cutter to make the mount holes elongated such that it will fit Smittybuilt, and Warn style roller fairleads? It might take an extra half a second in manufacturing, but would open up a MUCH larger market for your product!
Bypassing that issue, the install went very smoothly.
Step #1. Gather tools needed. These include a Phillips head screwdriver, Outward opening spring clip pliers, a 1/4" socket set with extension and U joint, and a set of metric allen wrenches.
Step #2. Unbo the unit, and remove the protective plastic from the metal surfaces.
Step #3. Using the small flat head screws and locknuts, attach the plastic clips to the metal frame.
Step #4. If your fairlead is installed correctly, the spring clips will be on the BOTTOM of the roller fairlead. Careful remove the clips and pins leaving the rollers in place.
Step #5. Assemble the license plate to the frame. Top of plate goes toward the hinge.
Step #6. With license plate facing away from you, line up the mount holes in the hinge ears to the holes in the fairlead, and reinstall pins.
Step #7. Reinstall spring clips. If you have them available, now might be a good time to get new ones put on.
If you did everything correctly you should be able to swing the plate down into position, and click it on to your rollers to secure it. Pulling in a rotating motion from the bottom of the plate unhooks it and the spring swings it up and out of the way to allow for winch use...
This thing is just so brilliant, and necessary for those of us in 2 plate states to avoid tickets that it ought to be included with the winch, or at least the fairlead... Like I said, this thing is brilliant!
Speaking of brilliant, there is ONE configuration I can think of where this will NOT work... On my fairlead there are holes right behind the pin holes to mount off road lights. If those lights were mounted, they would interfere with the operation of the plate bracket. Long story short, won't work, at least not well...
Now that I am done, I have a solid, secure, and somewhat good looking plate mount that keeps me from getting the attention of my local police department.
All things considered, a win win for me!
28 September, 2014
Picking up supplies for projects... Not much shop time.
Although this was technically a long weekend for me as I had 3 days off of my regular job, I wasn't able to get much actual shop time. I have been spending quality time on the road here and there, visiting with in laws, doing other various bits of business that took me up into Houston... so a trip to 4 Wheel Parts Wholesalers was in order. Anyone that has been in the off road scene for more than 10 minutes knows that the word Wholesalers in 4 wheel parts name is a LIE... but I digress...
You see the Chrome lug nuts for my truck are old enough, well... the chrome is peeling off. So I had a fresh set on order and needed to pick them up...
While I was there, I needed to replace the roller fairlead license plate mount bracket. The one that I Have now simply clips to the rollers and is super easy to steal...I picked up a license plate mount that is supposed to swing up and away from the fairlead when released, yet remain firmly mounted on the truck to at least somewhat deter easy theft. There are NO instructions what so ever, and at first glance, the way the mount is built does not appear to be able to function at all, but a second look and some mechanical reasoning shows how it goes together and works.
I am not going to bother doing a video on replacing lug nuts. If my audiencce can't figure lug nuts I need to seriously reasses who I think my audience is...
rein
So the projects I see in the plan for the video shoots in the near future are...
#1. Complete the 7 pin trailer harness // reverse lighting installation.
#2. Roller Fairlead License Plate holder installation. This is going to be important to those that live in states that require both a front and a rear plate, and you have a winch installed. Apparently winch mount designers do NOT take license plate relocation into accout, at all...
#3. Shop cleanup / organization. More the organizing part. I have need for storage space for household consumable items such as light bulbs, etc... and I know just the spot to put them... This is likely going to be a small cabinet build project in here as well.
#4. Structured wiring install. This is NOT going to be enclosed as my structured wiring project is far too large for any enclosures. Instead it will be rack mounted and include a KVM, 16 port gigabit switch, 16 port patch panel, VoIP adapter, router, modem the whole shebang...
#5. Office Depot particle board filing cabinet reinforcement project. Pretty simple one, but important. My office move is going to require it...
#6. overhead book storage. Simply put, the bookshelves are going away, and I need places to store my tech books, as well as recreational reading books, cookbooks etc...
Be patient with me on this whole thing. I am squeezing it in when I can, I know sevveral of y'all are chomping at the bit about the LED reverse light project, and I have heard from others about when am I going to get back to making sawdust... It's all coming God willing, please be patient... My recording / editing environment is almost complete. I will have the capacity soon, and hopefully I can sneak away from my wife's schedule plans long enough to get this done for you!
You see the Chrome lug nuts for my truck are old enough, well... the chrome is peeling off. So I had a fresh set on order and needed to pick them up...
While I was there, I needed to replace the roller fairlead license plate mount bracket. The one that I Have now simply clips to the rollers and is super easy to steal...I picked up a license plate mount that is supposed to swing up and away from the fairlead when released, yet remain firmly mounted on the truck to at least somewhat deter easy theft. There are NO instructions what so ever, and at first glance, the way the mount is built does not appear to be able to function at all, but a second look and some mechanical reasoning shows how it goes together and works.
I am not going to bother doing a video on replacing lug nuts. If my audiencce can't figure lug nuts I need to seriously reasses who I think my audience is...
rein
So the projects I see in the plan for the video shoots in the near future are...
#1. Complete the 7 pin trailer harness // reverse lighting installation.
#2. Roller Fairlead License Plate holder installation. This is going to be important to those that live in states that require both a front and a rear plate, and you have a winch installed. Apparently winch mount designers do NOT take license plate relocation into accout, at all...
#3. Shop cleanup / organization. More the organizing part. I have need for storage space for household consumable items such as light bulbs, etc... and I know just the spot to put them... This is likely going to be a small cabinet build project in here as well.
#4. Structured wiring install. This is NOT going to be enclosed as my structured wiring project is far too large for any enclosures. Instead it will be rack mounted and include a KVM, 16 port gigabit switch, 16 port patch panel, VoIP adapter, router, modem the whole shebang...
#5. Office Depot particle board filing cabinet reinforcement project. Pretty simple one, but important. My office move is going to require it...
#6. overhead book storage. Simply put, the bookshelves are going away, and I need places to store my tech books, as well as recreational reading books, cookbooks etc...
Be patient with me on this whole thing. I am squeezing it in when I can, I know sevveral of y'all are chomping at the bit about the LED reverse light project, and I have heard from others about when am I going to get back to making sawdust... It's all coming God willing, please be patient... My recording / editing environment is almost complete. I will have the capacity soon, and hopefully I can sneak away from my wife's schedule plans long enough to get this done for you!
21 September, 2014
Business practices of folks we know...
So I have been under the weather this weekend, trying to get up to speed so that my work week isn't so painful, and i was talking airplanes with a fellow colleague of mine before i went out on training, which brought a former fellow church member from my old church over a decade ago, I remember he bought up a struggling little kit airplane company and moved operations to a little shop in Webster Texas.
Now mind you, I am trying what I can to stay within what I know of copyright law / fair use and respecting the privacy of the person I am talking about, however I kind of have to divulge at least the company name due to copyright. It is NOT my intention to point this individual out and say "See what a schmuck this guy is?" I am NOT passing judgement on him as a person, but rather trying to give warning to others about business mistakes while following dreams...
The product he was selling was somewhat viable enough for aviation enthusiasts, a small kit built experimental aircraft, he was manufacturing the kits and from what I understand even turn key airplanes to order.
And as I understand it, he had orders. No idea if it was enough, or if he actually had the finances to pull it off, but there were orders...
I had the chance to tour the shop when he initially set up, and it looked good, everything was clean, well organized, there was an engineers precision to the entire thing. It looked good.
He worked in a different department for the company I worked for for several years after I left the church I was in previously, and I never heard much about his manufacturing company, I figured he didn't talk about it much so that he was't in any way having a conflict of interest, and I can respect that...
I always wondered what happened to him and his company. I moved on, years ticked by, and I did some Googling about his name, and his business name in relation to the city it was in, and found, well... conflicting information on his doings particularly in the time frame about the time I left that church...
On one hand, he worked for a large well known organization having to do with Aerospace and was receiving numerous awards for his work, and innovations that helped his company along.
On the other hand, there were several posts, and even entire web sites set up and to this day maintained talking about the poor and unethical business practices of his own privately held company.
Major issues such as taking payment in full, and never delivering product, failure to respond to communication attempts, up to and including registered mail, and finally just closing up shop and disappearing...
I know he had other life issues at the same time, not sure if one led to the other, not all that concerned either as it isn't my business or my point....
What I knew of this guy is this, he had a huge passion for aviation, and crazy good skills in Aerospace engineering, he came across an opportunity to pursue the dream to be one of the names remembered forever as a major contributor to his field, and I honestly think that is something in some way or another we want to leave a mark, a legacy that says we did something important. Now building kit airplanes isn't the end all be all for most of us I bet, but I bet would love to be known for leaving our influence much in the same was as Norm Abram, or Zora Arkus Duntov (car guys will know...) or, well whoever...
But if we go about it recklessly, without sufficient backing, and a solid business plan, we stand to leave behind a much more shameful legacy, more like a cautionary tale than an inspirational story.
And worse yet, if you count yourself among the faithful, you stand to tarnish what could have been a great ministry, and end up being at best a poor ambassador for your faith.
I know like I said above, many of us have our own dream we are following, whether it is the big corporate job, a little shop of our own, or some network marketing opportunity, or just some silly blog / podcast (who does THAT still?!), give it your all, and don't ever short change your customers / audience. If you don't have the funds to follow through with the job at hand, don't take the job in the first place. Or get financial backing. We live in the age or Kickstarter, and GoFundMe, not to mention direct donations / payments for capitol. Maybe, just maybe start your thing up as a hobby and grow it from there,.
If you do it right, and honest, and fail, you can look your customer square in the eye with a good conscience and say, "I did all I could, since I couldn't come through, here is your refund, and thank you for the trust you put in me!"
Don't let your dreams die just because of a setback or two, if your dream is to be, it will, find the right way to do it, and go for it!
Speaking of going for it, and being under the weather, I am on day 3 of my Z Pack, hopefully thing respiratory thing will be clear by mid week, and I can con my lovely wife into helping out with material for my next installation. Faux Talavera pottery. Yeah I am trying to get her flower pots out of my shop...
I am realizing much to my chagrin that my cell phone takes true HD video and my 2006 digital camcorder does not. To that end, I have rigged a phone adapter to my tripod, and am getting consistently better at shooting with the phone.
The sound recording gear is all funded (and as soon as the check clears to Discover, paid off), I just have one last piece that has not come in yet, which is a pop filter for my mic, Apparently they shipped in via sail powered cargo ship from China, and then mule train overland to get here... That is the bad, the good is, the mic is sensitive enough I don't need to be close enough to the mic to need a pop filter... So that is pretty awesome...
Now mind you, I am trying what I can to stay within what I know of copyright law / fair use and respecting the privacy of the person I am talking about, however I kind of have to divulge at least the company name due to copyright. It is NOT my intention to point this individual out and say "See what a schmuck this guy is?" I am NOT passing judgement on him as a person, but rather trying to give warning to others about business mistakes while following dreams...
The product he was selling was somewhat viable enough for aviation enthusiasts, a small kit built experimental aircraft, he was manufacturing the kits and from what I understand even turn key airplanes to order.
And as I understand it, he had orders. No idea if it was enough, or if he actually had the finances to pull it off, but there were orders...
Scan of a promotional postcard front for
the Airborne Innovations Wizard.
Scan of promotional postcard rear for
the Airborne Innovations Wizard.
He worked in a different department for the company I worked for for several years after I left the church I was in previously, and I never heard much about his manufacturing company, I figured he didn't talk about it much so that he was't in any way having a conflict of interest, and I can respect that...
I always wondered what happened to him and his company. I moved on, years ticked by, and I did some Googling about his name, and his business name in relation to the city it was in, and found, well... conflicting information on his doings particularly in the time frame about the time I left that church...
On one hand, he worked for a large well known organization having to do with Aerospace and was receiving numerous awards for his work, and innovations that helped his company along.
On the other hand, there were several posts, and even entire web sites set up and to this day maintained talking about the poor and unethical business practices of his own privately held company.
Major issues such as taking payment in full, and never delivering product, failure to respond to communication attempts, up to and including registered mail, and finally just closing up shop and disappearing...
I know he had other life issues at the same time, not sure if one led to the other, not all that concerned either as it isn't my business or my point....
What I knew of this guy is this, he had a huge passion for aviation, and crazy good skills in Aerospace engineering, he came across an opportunity to pursue the dream to be one of the names remembered forever as a major contributor to his field, and I honestly think that is something in some way or another we want to leave a mark, a legacy that says we did something important. Now building kit airplanes isn't the end all be all for most of us I bet, but I bet would love to be known for leaving our influence much in the same was as Norm Abram, or Zora Arkus Duntov (car guys will know...) or, well whoever...
But if we go about it recklessly, without sufficient backing, and a solid business plan, we stand to leave behind a much more shameful legacy, more like a cautionary tale than an inspirational story.
And worse yet, if you count yourself among the faithful, you stand to tarnish what could have been a great ministry, and end up being at best a poor ambassador for your faith.
I know like I said above, many of us have our own dream we are following, whether it is the big corporate job, a little shop of our own, or some network marketing opportunity, or just some silly blog / podcast (who does THAT still?!), give it your all, and don't ever short change your customers / audience. If you don't have the funds to follow through with the job at hand, don't take the job in the first place. Or get financial backing. We live in the age or Kickstarter, and GoFundMe, not to mention direct donations / payments for capitol. Maybe, just maybe start your thing up as a hobby and grow it from there,.
If you do it right, and honest, and fail, you can look your customer square in the eye with a good conscience and say, "I did all I could, since I couldn't come through, here is your refund, and thank you for the trust you put in me!"
Don't let your dreams die just because of a setback or two, if your dream is to be, it will, find the right way to do it, and go for it!
Speaking of going for it, and being under the weather, I am on day 3 of my Z Pack, hopefully thing respiratory thing will be clear by mid week, and I can con my lovely wife into helping out with material for my next installation. Faux Talavera pottery. Yeah I am trying to get her flower pots out of my shop...
I am realizing much to my chagrin that my cell phone takes true HD video and my 2006 digital camcorder does not. To that end, I have rigged a phone adapter to my tripod, and am getting consistently better at shooting with the phone.
The sound recording gear is all funded (and as soon as the check clears to Discover, paid off), I just have one last piece that has not come in yet, which is a pop filter for my mic, Apparently they shipped in via sail powered cargo ship from China, and then mule train overland to get here... That is the bad, the good is, the mic is sensitive enough I don't need to be close enough to the mic to need a pop filter... So that is pretty awesome...
20 September, 2014
Taking a break from one technology and getting a little, very little bit of shop time in today...
This past week I spent in a training boot camp as it were for study for my Red Hat Certified Engineers exam, only to realize that the class wasn't nearly long enough to cover all the new material to be tested on. But at least they gave us the books to study, and I can whip up a virtual machine pretty quick....
With my head in virtual meltdown mode, and fighting off some sort of respiratory and now ear infection, I opted to spend a little bit of time relaxing, and, well trying to get a few of the items on my to do list into the DONE pile...
I have moved the music equipment from the master bedroom into where the music room / recording studio / and home office will be. The String Swing mounts went up, and I made a HUGE mistake measuring for the holes. I assumed String Swing had them evenly spaced from the sides... They did not, so my mount blocks are somewhat off kilter. (grumble grumble...). I did luck out though, the spot where the Ibanez SR480 is now hanging, was directly over a stud. So I have rock solid mounting for my good bass. The old bang around bass however, not so much...
I dug up some wiring raceway that I had left over from an ethernet project from years past, and will use that for running the audio cables over the doorway from amp line out to mixer in.
I spent some time again covering my wife's flower pots that are sucking up my workbench wWith ith white paint. I REALLY need to get that shop straightened up! The Faux Talavera pot project is taking up far too much time, and I wasn't really expecting this to be a me only project... I need to con my wife into coming out to the shop and grabbing a brush for her flower pots...
I have been working on editing audio, and videos now for FAR too long, for me to FINALLY realize that my Galaxy S4 takes FAR better video than my 2006 digital camcorder. And better photos than my 2009 Digital Camera...
With that being said, I went ahead and ordered up a tripod mount for the phone. I am thinking about grabbing one of those grabby little flexible tripods that grips stuff for doing things like under car video shoots. I REALLY need to use one for moving forward with the trailer wiring / LED mod project. It kind of has me stuck since I am trying to do it as a video project for you guys...
Well folks, it's time to hit the meds, and the books again. I already know I will be asleep before I get 3 pages into the reading again. Almost not worth it...
With my head in virtual meltdown mode, and fighting off some sort of respiratory and now ear infection, I opted to spend a little bit of time relaxing, and, well trying to get a few of the items on my to do list into the DONE pile...
I have moved the music equipment from the master bedroom into where the music room / recording studio / and home office will be. The String Swing mounts went up, and I made a HUGE mistake measuring for the holes. I assumed String Swing had them evenly spaced from the sides... They did not, so my mount blocks are somewhat off kilter. (grumble grumble...). I did luck out though, the spot where the Ibanez SR480 is now hanging, was directly over a stud. So I have rock solid mounting for my good bass. The old bang around bass however, not so much...
I dug up some wiring raceway that I had left over from an ethernet project from years past, and will use that for running the audio cables over the doorway from amp line out to mixer in.
I spent some time again covering my wife's flower pots that are sucking up my workbench wWith ith white paint. I REALLY need to get that shop straightened up! The Faux Talavera pot project is taking up far too much time, and I wasn't really expecting this to be a me only project... I need to con my wife into coming out to the shop and grabbing a brush for her flower pots...
I have been working on editing audio, and videos now for FAR too long, for me to FINALLY realize that my Galaxy S4 takes FAR better video than my 2006 digital camcorder. And better photos than my 2009 Digital Camera...
With that being said, I went ahead and ordered up a tripod mount for the phone. I am thinking about grabbing one of those grabby little flexible tripods that grips stuff for doing things like under car video shoots. I REALLY need to use one for moving forward with the trailer wiring / LED mod project. It kind of has me stuck since I am trying to do it as a video project for you guys...
Well folks, it's time to hit the meds, and the books again. I already know I will be asleep before I get 3 pages into the reading again. Almost not worth it...
17 September, 2014
T Splice Demo Cleaned Audio
T splice soldering demo video. Same one I had uploaded before, only changes made was that I used the full version of Power Director instead of demo, and I cleaned up the audio in Audactiy. It's not perfect, but it is MUCH easier to listen to this way...
14 September, 2014
Fixing what's not broken, and a bit of a review on what I use to bring this to you...
Okay folks, I have been just swamped, beyond words swamped... I am presently over my head with things to do. I am working my day job, have several other irons in the fire, and am working on the podcasting / video podcasting setup and shooting videos etc...
I was planning on shooting a quick video and write up of fixing a compressed air piping system leak as I found a leak at the thread joint in the manifold, well I had disconnected the manifold and let it sit while I worked on other issues, and honestly got time away from my studies, my work, and my wife, and went out to do the video and fix the leak...
Guess what disappeared?
If you guessed that the leak went away nowhere to be found you'd be 100% correct!
Go figure...
Oh well, so that's a bust. I bet it will leak again, I should be more ready to tackle it next time anyway...
So, instead of a video on the fixing of compressed air plumbing leaks, I present to you now the maiden voyage of my current, and likely final audio recording setup for the podcasts, and video podcasts. I am set up with a Behringer XENYX 1202FX mixer, Behriner UCA200 USB Audio Interface, a Neewer XLR cable / microphone boom arm and shock mount, and a Behringer C1 large diaphragm condenser microphone. I have a pop filter on the way, but looking at the delivery date scheuled, it must be coming by sailing ship from China... The nice thing about this particular mic though is it is sensitive enough I can have the mic far away from my mouth and still pick up my voice quite nicely!
Well, there it is, thanks for watching, and hopefully you got something out of this!
I was planning on shooting a quick video and write up of fixing a compressed air piping system leak as I found a leak at the thread joint in the manifold, well I had disconnected the manifold and let it sit while I worked on other issues, and honestly got time away from my studies, my work, and my wife, and went out to do the video and fix the leak...
Guess what disappeared?
If you guessed that the leak went away nowhere to be found you'd be 100% correct!
Go figure...
Oh well, so that's a bust. I bet it will leak again, I should be more ready to tackle it next time anyway...
So, instead of a video on the fixing of compressed air plumbing leaks, I present to you now the maiden voyage of my current, and likely final audio recording setup for the podcasts, and video podcasts. I am set up with a Behringer XENYX 1202FX mixer, Behriner UCA200 USB Audio Interface, a Neewer XLR cable / microphone boom arm and shock mount, and a Behringer C1 large diaphragm condenser microphone. I have a pop filter on the way, but looking at the delivery date scheuled, it must be coming by sailing ship from China... The nice thing about this particular mic though is it is sensitive enough I can have the mic far away from my mouth and still pick up my voice quite nicely!
Well, there it is, thanks for watching, and hopefully you got something out of this!
09 September, 2014
Haven't forgotten about y'all... Sidelined with work, and setting up the recording studio.
I have a few videos being processed and voiced over right now for the blog, but for the most part, I am swamped with paid work, and studying for my upcoming RHCE exam. Yes I am a Linux geek. It pays the bills, so I need to keep up with it...
No small part of my voice over work is going to require moving my home office, which has been in the planning stages for several years now, and is finally coming into reality. The reason for this is actually multiple reasons.
#1. My current home office has the outside AC unit just below the window, I get LOTS of AC noise in the office / studio, meaning I have to run my gain way down, and do a LOT of noise filtering, which makes my voice sound muddy.
#2. The wall / door / window layout of the current office does not work with the larger pieces of wall centric furnishings needed for the office. The new one does.
#3. The new office is central to the house, and as such, will make it somewhat easier to finish up the structured wiring project for the house. I am NOT enclosing in a cabinet though. My structured wiring will be run into a wall mounted rack. Considering the size of my IP network, it's MUCH better this way. Anything that CAN have a wired IP connection WILL. I know 802.11ac can go up to 1750mbps, but in actual function, isn't likely to. I prefer hard wired. I know I'm werid.
#4. The remodel project is making me purge junk from the spare bedroom and home office. By the time I have the office moved into the new room, I should just have to slap paint on ceiling, walls and trim, rip out carpet and tack strip, lay down laminate, replace junk sockets and switches for fresh Decora units, Clean / repaint ceiling fan (white blades are turning gray). Swap out old window covering for new "Texas Flag Theme" window coverings, move furnishings and knick knacks in, make the bed with the "Texas Flag Theme" bedding, and call it DONE.
FWIW, the bed is a Full size memory foam mattress on a roller frame that I will be building a Texas Star 2x4 and panel headboard for. (Already have the design, just need to build it).
I will be setting up the home office / recording studio for multiple purposes. I mentioned it was to be a music room..
My music room equipment configuration plan is also complete. I haven't yet decided on a digital piano, but my wife wants one, so I am planning to put one in. The guitar and guitar amp actually belong to a friend, however he is looking to sell to me for a fair price.
During the remodel I will be doing some video of removing carpet, tack strip, filing and smoothing the concrete and laying down the laminate. I hope you folks are going to stick around with me long enough to catch the videos and enjoy them! I need to figure out a way to speed up my work flow!
No small part of my voice over work is going to require moving my home office, which has been in the planning stages for several years now, and is finally coming into reality. The reason for this is actually multiple reasons.
#1. My current home office has the outside AC unit just below the window, I get LOTS of AC noise in the office / studio, meaning I have to run my gain way down, and do a LOT of noise filtering, which makes my voice sound muddy.
#2. The wall / door / window layout of the current office does not work with the larger pieces of wall centric furnishings needed for the office. The new one does.
#3. The new office is central to the house, and as such, will make it somewhat easier to finish up the structured wiring project for the house. I am NOT enclosing in a cabinet though. My structured wiring will be run into a wall mounted rack. Considering the size of my IP network, it's MUCH better this way. Anything that CAN have a wired IP connection WILL. I know 802.11ac can go up to 1750mbps, but in actual function, isn't likely to. I prefer hard wired. I know I'm werid.
#4. The remodel project is making me purge junk from the spare bedroom and home office. By the time I have the office moved into the new room, I should just have to slap paint on ceiling, walls and trim, rip out carpet and tack strip, lay down laminate, replace junk sockets and switches for fresh Decora units, Clean / repaint ceiling fan (white blades are turning gray). Swap out old window covering for new "Texas Flag Theme" window coverings, move furnishings and knick knacks in, make the bed with the "Texas Flag Theme" bedding, and call it DONE.
FWIW, the bed is a Full size memory foam mattress on a roller frame that I will be building a Texas Star 2x4 and panel headboard for. (Already have the design, just need to build it).
I will be setting up the home office / recording studio for multiple purposes. I mentioned it was to be a music room..
My music room equipment configuration plan is also complete. I haven't yet decided on a digital piano, but my wife wants one, so I am planning to put one in. The guitar and guitar amp actually belong to a friend, however he is looking to sell to me for a fair price.
During the remodel I will be doing some video of removing carpet, tack strip, filing and smoothing the concrete and laying down the laminate. I hope you folks are going to stick around with me long enough to catch the videos and enjoy them! I need to figure out a way to speed up my work flow!
04 September, 2014
Cleaning up non shop related messes, and fixing a HUGE design flaw.
One of the serious drawbacks to having a home workshop that is physically attached to the home A.K.A. in the garage is spouses.
Simply put my wife's flower pots are pretty much everywhere in the shop now (again). She wanted to paint the pots to mimic Mexican Talavera pottery, put them all out in my shop, along with the supplies, and has since forgotten about them...
I need to gather them up, stash them in the corner with the lawn and garden stuff and get them away from my workspace.
I also have plenty of self induced chaos that I need to clear up. Tools need to go back into the tool box and cabinets, supplies need to be stashed where they belong, and overall the shop needs a good sweeping...
Once the shop is clean, and vaguely presentable, I plan on starting back up on my video series, and do a video on soldering etc...
I have recently assembled one of those particle board filing cabinets (the demo model in store was DEFINATELY a combination of ply and solid wood, this particle board ticks me off to no end but I digress), and there was a HUGE problem with assembly. The back panel of the filing cabinet, the one that keeps it from racking, well the so called hardboard was nothing more than overglorified cardboard, and the nails pulled through almost instantly. I have LOTS of tempered hardboard in the shop. Which is one reason to get the shop clean, so I can cut a proper sized hardboard back panel and attach it. I will likely use pnuematic nails and glue to make sure it doesn't go anywhere. I am also planning on adding some bracing / glue blocks for leveling feet.
If nothing else, I have a set of decent dimensions to work out a filing cabinet / drawer plan for myself to come up with a plan and build from.
22 August, 2014
The Daves Workshop / Wildersport Outdoors podcasting audio studio is live!
I have the audio studio set up and tested. I put up a video / audio clip slideshow on youtube walking you through... Like I said, I am working my tail off trying to get Daves Workshop media to be first rate to make your time spent here to be as enjoyable and productive as possible!
I wasn't happy with my sound editing on the video I initially posted. I made some changes, and re-uploaded the video, the URL has changed, take a peek, it sounds MUCH better. (Thank God for Audacity Compressor function!)
Thanks for visiting.
I wasn't happy with my sound editing on the video I initially posted. I made some changes, and re-uploaded the video, the URL has changed, take a peek, it sounds MUCH better. (Thank God for Audacity Compressor function!)
Thanks for visiting.
17 August, 2014
XENYX 502 Podcaststudio usb mic port test
I have been in discussion with some folks about this issue. In my efforts to produce a better product for my readers / viewers I am wanting to produce quality audio, and video, I made this quick and honestly lazy presentation / test of the mixing board that came with my podcaststudio kit, and shows how a simple, very small mixer will allow for multiple microphone connections. Admittedly the channel 2 connection isn't ideal as it bypasses the equalizer circuitry, but it will work well enough for studio guests if I ever get them in... Yes folks I have ideas for where I want to take this blog, and I am looking at breaking into podcast / video podcasting territory...
11 August, 2014
Crash course to better serve my readers / viewers!
I am wanting to provide instructional / educational resources on my blog, and honestly the audio from my Camcorder stinks. I am also considering making a recurring podcast for those audio oriented folks, so I am crash coursing on using some home recording gear that is not attached to the camera, doing some intense video editing, and other multimedia work that I honestly haven't done any of since before Adobe Systems acquired Macromedia, so if it seems like I am taking longer between posts, there is a good reason for it. Think of it as the human version of electrolysis rust removal for the brain...
And before I get any more email on the subject, I wanted to let everyone know what I am doing with this blog / video / podcast I am hoping to make completely unique. While you will undoubtedly see similarities between my content, and the content of others, and I would be lying if I said others don't inspire me and my desire to dive deeper down this rabbit hole, I first and foremost have fun with what I am doing, I don't limit myself to talking about just one subject (Such as woodworking, automotive, outdoorsmanship, faith, family, etc...) rather I am using this as a platform to cover what interests me, and I use it as a way to help you along the process. I assume some knowledge, but try to keep that assumption as basic as possible, and I am open to feedback. If I went over something too fast, ask me for clarification and I will be more than happy to oblige!
I sincerely hope you enjoy the content I am putting up here as much as I enjoy creating it for you, and that you express that enjoyment by either donating to my site by purchasing products from my Amazon Store. And of course you are free to send a gift via PayPal with the PayPal link on the main page. Sadly the PayPal and Amazon e-stores don't link together... I will post up the best bargains I can find on anything and everything that I think might be of interest, and certainly what I feature in my posts, assuming it is available on Amazon. I will also let you know when an item is better priced elsewhere! Your purchases and gifts will help offset my costs, and help me justify what I am doing with this to my wife thus enabling me to keep diving down this crazy rabbit hole!
And before I get any more email on the subject, I wanted to let everyone know what I am doing with this blog / video / podcast I am hoping to make completely unique. While you will undoubtedly see similarities between my content, and the content of others, and I would be lying if I said others don't inspire me and my desire to dive deeper down this rabbit hole, I first and foremost have fun with what I am doing, I don't limit myself to talking about just one subject (Such as woodworking, automotive, outdoorsmanship, faith, family, etc...) rather I am using this as a platform to cover what interests me, and I use it as a way to help you along the process. I assume some knowledge, but try to keep that assumption as basic as possible, and I am open to feedback. If I went over something too fast, ask me for clarification and I will be more than happy to oblige!
I sincerely hope you enjoy the content I am putting up here as much as I enjoy creating it for you, and that you express that enjoyment by either donating to my site by purchasing products from my Amazon Store. And of course you are free to send a gift via PayPal with the PayPal link on the main page. Sadly the PayPal and Amazon e-stores don't link together... I will post up the best bargains I can find on anything and everything that I think might be of interest, and certainly what I feature in my posts, assuming it is available on Amazon. I will also let you know when an item is better priced elsewhere! Your purchases and gifts will help offset my costs, and help me justify what I am doing with this to my wife thus enabling me to keep diving down this crazy rabbit hole!
02 August, 2014
Making the tee splice in the 7 pin wiring harness.
Hopefully you can make heads or tails of the video. Sorry. I obviously have not figured out the finery of Youtube video publishing... Hopefully I will get better, soon...
If you have been following this on the forum, you will notice the use of a yellow wire to tie into a red wire. That is intentional as it meets the requirements of my documented circuit design.
As a reminder the design of the circuit is as follows...
12V red power feeds the hot side of supply side of a SPST illuminated switch which is already installed in the dashbaord. Sorry if you wanted to see that done. I figured that was so basic as to not be worth my effort of documenting... I can do a fresh one if you'd like... Another 12V red power feed runs and terminates at terminal 87 on the relay. Thus feeding power to the relay.
The load side of the SPST switch is a green wire in the diagram, I will likely use white as it is what I have, and is routed to share a common lug with the yellow wire we just soldered on, and those will terminate on terminal 86 of the relay.
Terminal 85 will have a black wire run to a grounded ring terminal.
Terminal 30 will be a blue wire feeding back, and a Y splice shooting 2 wires off, 1 to each of the LED reverse lamps. (The 2 pin couplers actually). The couplers other side will be soldered to a short black lead attaching to ring terminals at the mount and grounding as close as possible to the mount.
As many of the connections as possible will be either weathertight, or soldered. I don't EVER want water problems with my circuit...
I MAY switch wire color from switch to relay to blue, and use white wire from relay to lamps. The lamps are factory wired white / black, and I don't have any green wire. The relay is to be mounted underhood, so I am figuring I will need to carry 2 wires via a split loom to the front of the truck from the back, the yellow signal wire from the reverse light circuit, and the white power feed wire to the lamps. The relay can be grounded in the engine compartment, and the lamps themselves can be grounded at the frame mounting tab the lamps will mount to. This will minimize the amount of wire actually run throughout the vehicle, and theoretically at least, minimize the weight gain on the truck, by at least a few ounces, but every bit adds up!
A close up view, and sorry my camera work is a little jiggly here, but that red wire is heading straight to the center pin. According to every manual I have seen that is the reverse light wire, so that is the one we are going after!
So we fish back through the split loom a few inches back and fish that red wire out so we can trim the insulation off of it and make our solder joint. My camera work here is MUCH better as I wasn't trying to one hand it...
Strip back the insulation on the wire you are going to solder to the main, stripping enough insulation to make 5 full turns around the main wire.
If using stranded wire, twist the wires together before wrapping, at least this is the habit I got into. When you are done with your wraps it should look like the photo above...
26 July, 2014
Notice to spammers...
You guys must be a special kind of stupid...
I moderate comments and while I will approve comments that disagree with me or take contrary view points, spam will be rejected offhand and reported.
For what it's worth I believe spammers should be rolled naked in thumb tacks and dipped in rubbing alcohol and rubbed down with salt.
But keep your chins up. In my book spammers still rank above Lawyers and child molesters... Ever so slightly, but still above.
I moderate comments and while I will approve comments that disagree with me or take contrary view points, spam will be rejected offhand and reported.
For what it's worth I believe spammers should be rolled naked in thumb tacks and dipped in rubbing alcohol and rubbed down with salt.
But keep your chins up. In my book spammers still rank above Lawyers and child molesters... Ever so slightly, but still above.
25 July, 2014
Hunting and gathering for the trailer light / backup light installation.
So as of noon today, almost everything I need for this project is in hand, I think...
Large ring terminals for 22 ga wire seem to be extensively difficult to come by, so I am going to take a different approach, I have 2 wires that need to be ring connected to the battery stud, a 22 ga wire for the switch, and either 22 or 16 ga wire to go to the relay. So I figure I use a 16-14 ga ring terminal with a 1/4" ring and solder the two wires together and crimp that all it, I should be good to go!
Large ring terminals for 22 ga wire seem to be extensively difficult to come by, so I am going to take a different approach, I have 2 wires that need to be ring connected to the battery stud, a 22 ga wire for the switch, and either 22 or 16 ga wire to go to the relay. So I figure I use a 16-14 ga ring terminal with a 1/4" ring and solder the two wires together and crimp that all it, I should be good to go!
The bag in the middle area is the relays, relay sockets, and ATC fuse holders. These things are major overkill for this task, but I am a firm believer in better safe than sorry... Not to the degree engineers are, but you get the idea...
Looking at the AWG ampacity ratings, my 2@ 18 watt lights will draw a total of 36 watts, and that means 3 amps, the charts for chassis wiring, which is what this technically is, rates 22 awg at 7 amps, WAY above what this will actually draw, or even think of drawing...
Now if we look back I think it was 3 posts ago, when I discussed designing the circuit, you will recall that the red wire comes from 12V source (battery) the black wire goes to chassis ground, and the blue wire feeds power to the lights.
It just so happens that I have the black and red wires in 16 ga, and digging through my toolbox I found 16 ga blue wire from the pilot off road lighting kit I never ended up using (and wish I knew where the relay from THAT went...)
In my digging to find my soldering iron, and spool of solder, I found a spool of white 16 ga wire as well... The green and yellow wires being signal wire being 22 ga is fine... So I am good to go, at least once I find the shrink tubing... I know I had it around here somewhere...
24 July, 2014
Dealing well with the pressures...
I just wanted to touch base with those that have been following my compressed air system journey. I realized my last entry on this issue was on June 8. I have been keeping the compressors powered off except when I am actively using them, but keeping the tanks pressurized. The system is holding pressure perfectly. The only time the compressors cycled was during hard use... I couldn't be happier...
Auxiliary LED reverse lighting continued. Prepping the brackets.
Simply put, these lights HAVE to work, and they HAVE to be out of the way when backing up, especially off road.
Now when I was considering how to add additional reverse lighting to my truck I will be completely honest, hanging LED fixtures were not at the top of my list. I was originally considering adding some of those 6" oval LED fixtures cut in to the rear bumper. Mostly for clearance sake. But I could see a minor bump in traffic causing damage, and honestly, I was having a very tough time finding sufficient quality fixtures for my application. Most of them are either REALLY expensive, or to be polite, severely lacking in build quality.
While I was looking for insipration, I came across F150Online.com member lakemarykid's beautiful Oxford White / Pueblo gold 2 tone 2007 F150 FX4 Supercrew. The job he did on the install looks great, although he is only powered by a dash switch.
Now when I was considering how to add additional reverse lighting to my truck I will be completely honest, hanging LED fixtures were not at the top of my list. I was originally considering adding some of those 6" oval LED fixtures cut in to the rear bumper. Mostly for clearance sake. But I could see a minor bump in traffic causing damage, and honestly, I was having a very tough time finding sufficient quality fixtures for my application. Most of them are either REALLY expensive, or to be polite, severely lacking in build quality.
While I was looking for insipration, I came across F150Online.com member lakemarykid's beautiful Oxford White / Pueblo gold 2 tone 2007 F150 FX4 Supercrew. The job he did on the install looks great, although he is only powered by a dash switch.
Now the brackets he used are something used in commercial construction, not readily available to the average DIYer, so I had to take a different approach, but then again, what I used followed the same idea at least...
Yes, there was some DIY to it...
Step #1. Look around the shop and see what I have on hand. The aluminum angle I was planning on using appears to be all used up, so option #2. Use flat steel and make it the shape I want...
Step #2. I know I want a 1.5 x 1.5 L section with 5/16" holes for the bolts, so I take the 1.5" wide steel stock and measure up 1.5" up, using a sharpie mark a fold line, another 1.5" up and mark a cut line...
Step #3. Secure the stock in the bench vise, and using my 4.5" angle grinder, Harbor Freight cut off wheels, and of course safety glasses, respiratory, and hearing protection, made my cut.
Step #4. Repeate step #s 2 and 3 for the second bracket.
Step #5. Using a straight edge and sharpie, mark center of each half segment so there are two X's on each piece.
Step #6. Using a punch and hammer, dimple the center to guide the drill bit.
Step #7. Secure the work pieces, and drill a 5/16" hole at each dimple.
Step #8. Using a file, clean up all cut lines, corners, and drill hole edges, insuring that a 5/16" fastener can easily pass through.
Step #9. Using a machinists vise, secure the work piece such that the fold line is just at the top of the jaw, and squared to the jaw. Lock the jaws down so the piece can not move, and using a large, broad headed steel hammer bend the pieces to a 90 degree angle.
Step #10. Using a disposable cloth paper towel, shop rag in a box type of rag, and at least rubbing alcohol if not a stronger solvent that does NOT leave a residue, thoroughly clean all surfaces.
Step #11. Scuff surfaces with sandpaper, clean off any dust / residue then prime, and paint with at least 3 coats of rust inhibiting paint. You can also use plastidip if you'd like.
Your brackets are now ready! You can go ahead and bolt the light to the bracket using the provided bolts, however I would suggest instead sourcing up stainless steel replacements, and an additional pair of 5/16 x I think it is 1" stainless steel bolt, flat washer, and nylon insert lock nut to secure to the frame of the truck...
So you want to know where to find the bargains?
Harbor Freight 4.5" angle grinder. If you have a HF close, these are so cheap even if it breaks after a year or so just toss it and get a new one... Mine is an older B&D I bought at Walmart, the HF grinder seems to be better made...
4.5" metal cut off wheel for the angle grinder? Yeah HF has those too! I have used the ones from the big box stores, and the HF ones actually seem to hold together better...
I could give you a link to online ordering the flat stock, or easier yet, aluminum angle but get the stuff locally. It will be cheaper. Shipping on that stuff with eat you up!
Center punch. Yeah Amazon has those cheap. The HF ones I have tried are junk. The Stanley is okay, great considering it is dirt cheap and likely to get lost before you dull it... I have them in my Amazon affiliate store.
If you are like me and like to have the big box of crayons to color with as it were, and like having your bits etc... come in large sets, probably THE most impressive set of bits I have used to date are the DeWalt pilot point bits. They do help make drilling metals much easier. The DW1969 29 piece set is on Amazon at the lowest price I have seen recently...
For a lower budget option, you could try the Warrior 29 piece Titanium Nitride bit set from Harbor Freight. Mind you, I have not tried them out yet so I can not attest to their quality, or even usefulness. If anyone wants to donate a set for testing I would happily accept and test the snot out of a set of these...
Most of the items needed for this project have arrived already. I have 2 items left to have come in, One was due to an error in my observation. They are...
#1. The Tow Read 118136 Universal plug mount bracket. I thought I didn't need it, but I was wrong. It happens...
#2 12 volt illuminated rocker switch with green LED. I figure instead of the high dollar switches, which mind you are ultra cool, but pricey, that LakeMaryKid used, I figured I would color code. Keep the Red LED rocker for the front off road lights, and use a green LED rocker for the rear reverse / flood lights.
Package tracking says I should have all that stuff in hand tomorrow afternoon, so I should be moving forward with this project, and some work on the Saturn this weekend...
So stick with me, and enjoy as I document how the project all comes together!
So you want to know where to find the bargains?
Harbor Freight 4.5" angle grinder. If you have a HF close, these are so cheap even if it breaks after a year or so just toss it and get a new one... Mine is an older B&D I bought at Walmart, the HF grinder seems to be better made...
4.5" metal cut off wheel for the angle grinder? Yeah HF has those too! I have used the ones from the big box stores, and the HF ones actually seem to hold together better...
I could give you a link to online ordering the flat stock, or easier yet, aluminum angle but get the stuff locally. It will be cheaper. Shipping on that stuff with eat you up!
Center punch. Yeah Amazon has those cheap. The HF ones I have tried are junk. The Stanley is okay, great considering it is dirt cheap and likely to get lost before you dull it... I have them in my Amazon affiliate store.
If you are like me and like to have the big box of crayons to color with as it were, and like having your bits etc... come in large sets, probably THE most impressive set of bits I have used to date are the DeWalt pilot point bits. They do help make drilling metals much easier. The DW1969 29 piece set is on Amazon at the lowest price I have seen recently...
For a lower budget option, you could try the Warrior 29 piece Titanium Nitride bit set from Harbor Freight. Mind you, I have not tried them out yet so I can not attest to their quality, or even usefulness. If anyone wants to donate a set for testing I would happily accept and test the snot out of a set of these...
Most of the items needed for this project have arrived already. I have 2 items left to have come in, One was due to an error in my observation. They are...
#1. The Tow Read 118136 Universal plug mount bracket. I thought I didn't need it, but I was wrong. It happens...
#2 12 volt illuminated rocker switch with green LED. I figure instead of the high dollar switches, which mind you are ultra cool, but pricey, that LakeMaryKid used, I figured I would color code. Keep the Red LED rocker for the front off road lights, and use a green LED rocker for the rear reverse / flood lights.
Package tracking says I should have all that stuff in hand tomorrow afternoon, so I should be moving forward with this project, and some work on the Saturn this weekend...
So stick with me, and enjoy as I document how the project all comes together!
22 July, 2014
Adding LED reverse lighting, and 7 pole trailer plug.
Anyone that has ever backed up in the dark, rainy, unlit night with factory reverse lights know the white knuckle braille experience it can be, now put yourself out on the deer lease, or in the mountains somewhere in those same conditions, you are going to want light and a lot of it...
Now my project here is twofold,
Fisrt off, I am wanting to add the final piece of the OEM "Towing Package" that my truck did not ship from Ford with and that is the 7 pin wiring pig tail under the rear bumper. It's a good thing this is a common part, and lots of the aftermarket produce OEM quality or better replacement pieces, and an even better thing that Ford designed the wiring harness to be modular. Simply snap on / snap off and you are good to go!
Second issue I need to tackle is the extreme need for radically improved back up lighting. Simply put, backing up this beast in the dark is a dangerous, white knuckle affair. I have wanted upgraded lighting on the tail end of this truck for years. And with the new LED lighting fixtures coming down radically in price, it looks like it is time to tackle this project! Tons of light, great durability, and greatly reduced power draw. What's not to like?
So first things first, design the setup and start hunting and gathering what I will need to make these changes, and get the knowledge I need to do the job...
Thankfully TowReady has part number 118247 trailer wiring and relay kit available at a variety of retailers. www.etrailer.com provides a pretty decent video instruction on how to install it. I WILL be varying my install from etrailers install. Their install is using a band clamp on a round tube trailer hitch, my hitch is square tube and I honestly think Etrailers use of a band clamp is beyond pitiful. It is barely better than bailing wire and bubble gum. I want this done RIGHT... So please ignore that part on their video. I will attampt to shoot and edit my own video on this project, so hopefully you will have something a bit better quality to work with...
Mind you, etrailer has been kind of nasty about this as they have disallowed embedding of the Youtube video, but I CAN give you the link... The video overall is decent, but like I said, they cut a HUGE corner quality wise in the install by relying on a band clamp. That just will not do!
Anyway the video link is HERE.
Like I promised on my forum posts, I will post the links to the products and the best prices I could find to get the job done, so if you go to my Amazon Store at http://astore.amazon.com/davework-20?_encoding=UTF8&node=14
There are 2 items that while I can find at Amazon that there are MUCH better buys at Harbor Freight tools if you have one of them close by...
127 piece Heat Shrink Tubing.
10 rolls 60ft 3/4" electrical tape.
I assume "normal" mechanical ability, and equipment. Feel free to add crimp connectors in place of solder connections. I personally prefer solder joints over crimp connectors, particularly in 4 wheel drive / off road applications.
So now that all the bits and pieces are on order, I ought to share with you the design for the circuit.
I am giving serious consideration to adding a 3amp diode inline on the feed line from the backup lights.
FWIW, this circuit design should work with any 12V DC vehicle with a factory back up lighting circuit where the desired end result is the accessory reverse lights turned on with both the vehicle being put in reverse, AND the lights being manually turned on with an interior mounted toggle switch with illumination that will allow you to tell if you accidentally left the lights on...
If I opt for the diode and I suspect I will so that I don't induce back feed into an unenergized reverse light circuit, the best price I have found so far is at Radio Shack...
http://www.radioshack.com/product/index.jsp?productId=2062578
So now that the design is shored up, and the parts are ordered (somehow Amazon Prime 2 day sometimes means 9 days...).
Before moving forward, there is some equipment you will need to round up. This is...
Now my project here is twofold,
Fisrt off, I am wanting to add the final piece of the OEM "Towing Package" that my truck did not ship from Ford with and that is the 7 pin wiring pig tail under the rear bumper. It's a good thing this is a common part, and lots of the aftermarket produce OEM quality or better replacement pieces, and an even better thing that Ford designed the wiring harness to be modular. Simply snap on / snap off and you are good to go!
Second issue I need to tackle is the extreme need for radically improved back up lighting. Simply put, backing up this beast in the dark is a dangerous, white knuckle affair. I have wanted upgraded lighting on the tail end of this truck for years. And with the new LED lighting fixtures coming down radically in price, it looks like it is time to tackle this project! Tons of light, great durability, and greatly reduced power draw. What's not to like?
So first things first, design the setup and start hunting and gathering what I will need to make these changes, and get the knowledge I need to do the job...
Thankfully TowReady has part number 118247 trailer wiring and relay kit available at a variety of retailers. www.etrailer.com provides a pretty decent video instruction on how to install it. I WILL be varying my install from etrailers install. Their install is using a band clamp on a round tube trailer hitch, my hitch is square tube and I honestly think Etrailers use of a band clamp is beyond pitiful. It is barely better than bailing wire and bubble gum. I want this done RIGHT... So please ignore that part on their video. I will attampt to shoot and edit my own video on this project, so hopefully you will have something a bit better quality to work with...
Mind you, etrailer has been kind of nasty about this as they have disallowed embedding of the Youtube video, but I CAN give you the link... The video overall is decent, but like I said, they cut a HUGE corner quality wise in the install by relying on a band clamp. That just will not do!
Anyway the video link is HERE.
Like I promised on my forum posts, I will post the links to the products and the best prices I could find to get the job done, so if you go to my Amazon Store at http://astore.amazon.com/davework-20?_encoding=UTF8&node=14
There are 2 items that while I can find at Amazon that there are MUCH better buys at Harbor Freight tools if you have one of them close by...
127 piece Heat Shrink Tubing.
10 rolls 60ft 3/4" electrical tape.
I assume "normal" mechanical ability, and equipment. Feel free to add crimp connectors in place of solder connections. I personally prefer solder joints over crimp connectors, particularly in 4 wheel drive / off road applications.
So now that all the bits and pieces are on order, I ought to share with you the design for the circuit.
FWIW, this circuit design should work with any 12V DC vehicle with a factory back up lighting circuit where the desired end result is the accessory reverse lights turned on with both the vehicle being put in reverse, AND the lights being manually turned on with an interior mounted toggle switch with illumination that will allow you to tell if you accidentally left the lights on...
If I opt for the diode and I suspect I will so that I don't induce back feed into an unenergized reverse light circuit, the best price I have found so far is at Radio Shack...
http://www.radioshack.com/product/index.jsp?productId=2062578
So now that the design is shored up, and the parts are ordered (somehow Amazon Prime 2 day sometimes means 9 days...).
Before moving forward, there is some equipment you will need to round up. This is...
- Factory jack, and handle for operating the spare tire winch.
- Wheel chocks, chunks of 4x4, whatever...
- Floor jack capable of safely lifting the truck. I opted for the Pittsburgh Automotive 4 ton item #68056. Purchased on sale, with a 25% off coupon so it wasn't that bad...
- Jack stands with sufficient height and weight handling capacity to give you ample room and safe load rating to work on the truck safely. I opted for the Pittsburgh Automotive 6 ton Steel Jack Stands item #61197. Same deal as the floor jack...
- I am not going to bother with linking one as you really ought to have it by now if you are wanting to take on this project, but you need a socket / ratchet set, deep well, in metric. The Etrailer video shows using an electric impact, no real need, and if I was going to I would go pnuematic not electric...
- Crimp tool.
- A basic soldering iron.
- Lighter.
- Drill and bits.
- Screwdriver set.
I'm sure I will come up with something I forgot about while I am actually working the project. I will make note of it in the video, AND come back and update the list here.
So for now I bid you a good night, and promise that I will post updates here in text, photo, and video here shortly!.
14 July, 2014
When rushed for time, don't rush...
As you know, Dave's Workshop is a hobby shop. The only thing professional about it is the tools I still own that I used when I was a professional mechanic lin my youth. Yeah those tools are now considered "Classic" so that should tell you something...
So as I hinted to, I have been busy, too busy, with things that actually pay the bills, and dealing with extended family issues. (Not going into too many details other to say we have had a couple of losses recently...)
Now with all of that, the projects that need to get done, well, take a back seat... And one of those projects has been repairing paint damage on the back of the cab, and front of the bed of my truck that was caused by the toolbox rubbing... So I tried to take what little time I had available, specifically while my wife was getting her nails done, and found an abandoned part of the parking lot, some wax and tar cleaner, clean rags, newspaper, frog tape, sandpaper / sanding block, and primer, not to mention the color coat...
Everything went great, until well... after.
It would appear in my haste to maximize my time, I didn't do a good enough masking job on the back window of the truck, OR between cab and bed. I now need to clean red primer off of the back glass, and spray a bit more color coat between cab and bed. THEN I need to move on to more wet sanding, and another coat or two of color before I move forward with clear...
Now this is the first time I have ever attempted this, and I must admit, I am scared senseless to try this, but I figure with the amount of paint damage that was there already, I had to try, or simply cough out for a fresh paint job...
Duplicolor has some great videos on actually how to do this, and I highly recommend anyone that wants to try this on their own, to dig up those videos on Youtube and watch them first....
So as I hinted to, I have been busy, too busy, with things that actually pay the bills, and dealing with extended family issues. (Not going into too many details other to say we have had a couple of losses recently...)
Now with all of that, the projects that need to get done, well, take a back seat... And one of those projects has been repairing paint damage on the back of the cab, and front of the bed of my truck that was caused by the toolbox rubbing... So I tried to take what little time I had available, specifically while my wife was getting her nails done, and found an abandoned part of the parking lot, some wax and tar cleaner, clean rags, newspaper, frog tape, sandpaper / sanding block, and primer, not to mention the color coat...
Everything went great, until well... after.
It would appear in my haste to maximize my time, I didn't do a good enough masking job on the back window of the truck, OR between cab and bed. I now need to clean red primer off of the back glass, and spray a bit more color coat between cab and bed. THEN I need to move on to more wet sanding, and another coat or two of color before I move forward with clear...
Now this is the first time I have ever attempted this, and I must admit, I am scared senseless to try this, but I figure with the amount of paint damage that was there already, I had to try, or simply cough out for a fresh paint job...
Duplicolor has some great videos on actually how to do this, and I highly recommend anyone that wants to try this on their own, to dig up those videos on Youtube and watch them first....
29 June, 2014
Fixing what the body shop set back to factory, and some perspective on the new fender flares...
So as you may recall, my truck had to spend some quailty time in the body shop due to an attempted theft / vandalism that caused some extensive damage to the drivers front fender, wheel, studs, and windshield. I finally get the truck back from the body shop that fixed what the first body shop royally messed up on, and I want to take the time here, since I knocked Cook Ford for the poor quality work, I want to credit Frede Chevrolet for exactly the opposite, although it took them a bit to get the parts in, more on that in a bit... they did first rate work. Everything was aligned properly, and fitted the way I would expect to see it..
Only problem is, they put it back to Factory, excluding the fender flares... They replaced the Damaged Pacer Performance flares, with EGR OEM Look flares. I am not going to complain, those were the flares I wanted in the first place, but couldn't ever seem to locate...
However, as I said, the body shop put the fender back to stock, meaning the plastic trim, and the steel lower / inner edge of the fender were put back where they were from Ford, and the 35x12.50/17s rubbed when I turned / hit a bump. I HAD to fix that again...
So now having some experience with this, I started the truck up, set the parking brake, made sure it was in park, and rolled the window doen...
I then got out of the truck, rolled the window down, and turned the wheel to the left (it is the back outer edge of the tire that hits), and watched where it came closest, and marked off about 1/2" past each way...
Turn the wheel to the lock the other way, and turned the truck off, and went to the shop...
Out came the air hose off of my hose reel, an air hammer, an air chisel hammer, and a pair of tin snips.
I trimmed the plastic, just outside of the marked lines, so that there was no longer any protruding plastic. Next I used the tin snips to re-cut the fold that the body shop tack welded back, and then the air hammer / chisel hammer bit came out and folded the sheet metal back well away from tire interference...
Only problem is, they put it back to Factory, excluding the fender flares... They replaced the Damaged Pacer Performance flares, with EGR OEM Look flares. I am not going to complain, those were the flares I wanted in the first place, but couldn't ever seem to locate...
However, as I said, the body shop put the fender back to stock, meaning the plastic trim, and the steel lower / inner edge of the fender were put back where they were from Ford, and the 35x12.50/17s rubbed when I turned / hit a bump. I HAD to fix that again...
So now having some experience with this, I started the truck up, set the parking brake, made sure it was in park, and rolled the window doen...
I then got out of the truck, rolled the window down, and turned the wheel to the left (it is the back outer edge of the tire that hits), and watched where it came closest, and marked off about 1/2" past each way...
Turn the wheel to the lock the other way, and turned the truck off, and went to the shop...
Out came the air hose off of my hose reel, an air hammer, an air chisel hammer, and a pair of tin snips.
I trimmed the plastic, just outside of the marked lines, so that there was no longer any protruding plastic. Next I used the tin snips to re-cut the fold that the body shop tack welded back, and then the air hammer / chisel hammer bit came out and folded the sheet metal back well away from tire interference...
There is now more than enough space for the suspension to flex.
The new flares offer close to full coverage of the tires.
Not fully covered, but close enough.
Road tested, and the tire rub is now completely gone over all surfaces I have been willing to try it on. Turning, large bumps etc... Still need to test it offroad, but that will be a bit...
IF the Rancho Quick Lift Loadeds had a strong enough spring, I am certain there would have been no interference problem, as I was running this same brand, model, and size tire with the stock struts and Auto Spring 2.5" leveling spacers.
But, with all the headache it has been getting to this point, there it is, done for now. 2004 F150 4x4 with 35x12.50/17 mud tires, Only suspension lift is a 2.5" Rancho coil spring / strut lift, 9K lb winch and heavy duty brush guard / winch mount, nerf bar steps to help my wife and I get into the truck easier. I do need to swap the Rancho coils for Moogs, but aside from that, and some minor cosmetic stuff, this truck has seen enough attention from me for a while. On to the Saturn!
24 June, 2014
Prepping for a show, and Ye Olde Heavy Metal...
The workshop is set up and staged for several projects, most notably my lovely bride and I are going to try to reproduce a Talavera-ish look on some large plain tera cotta flower pots. Considering the size she wants in real Talavera runs around $80 - $100 per flower pot, and our lawn service has been known to break flower pots when edging around them, I figured we can replicate the general look pretty easily with some $13.00 Home Depot pots and some Ceramics paint, finished off with full gloss brush on lacquer.
We picked the pots up from Home Depot yesterday, and as they had been rained on in the outdoor garden department, they needed to thoroughly dry before I attempted to paint them. So in the shop they went, unfortunately that takes up a LOT of room...
Another project I had, and this one was more time pressing, was to size up some replacement steel rods for my E-Z Up 13 x 13 Pagoda Gazebo Canopy.
The Auto Show is coming up, and my brother in laws body shop is setting up a booth, and he was going to borrow up the Pagoda to use in the booth, which is great, but unfortunately the last time my wife and I took it to the beach, we got run off the beach by some fast severe weather, and I forgot the extension rods that hold the what would be the eaves if this were a normal structure, out away from the verticals.
So I sized up the bores for the rods, and found that they are 1/2", I used some 1/2" hardwood dowel from the craft store to size up how long the rods should be. I talked with the support folks at EZ-Up, they would be more than happy to sell me replacements for $25.00 + S&H by the way... but they couldn't tell me for sure the length, apparently there are 2 different sizes, mine happened to be the 28", so...
Once the lengths were measured, the angle grinder with the HF metal cutoff wheel was brought out, and the rods were cut, the rough edges were dressed off by hand with a file, and the rods were thoroughly cleaned...
For the Auto Show. I won't bother with paint on the rod yet... But once I get done with that, I get the rods back to the shop, they will get thoroughly cleaned, roughed up with some sandpaper, and then primed, and painted. Mostly to keep rust away from the canopy fabric... The end that goes into the fabric pockets are going to be dipped in Plasti-Dip to finish the job up...
Now as promised in the title... I managed to stumble across a Youtube Channel courtesy of none other than Wil Wheaton, yes, I am that geeky that I follow Wil's blog, and have him in my Google+ circles, and controversial or not, I actually LIKED the Wesley Crusher character in Star Trek The Next Generation! but I digress...
Being a child of the 1980s, heavy metal was a staple of the music scene when I was a teen, and of course, as I ripen, uh I mean mature into the graceful (yeah right) age I am now... I find my musical taste varies quiet a bit more, and I appreciate the finer points of true art that I simply wasn't open to at a younger age. Combine that with far too many years with my fall seasons spent at the Renaissance Faire, and yes... I think I have acquired a fondness for the more obscure musical genres...
So without further Adieu, I present to you 2 classically trained harpists Camille and Kennerly with their cover of Iron Maidens "Fear Of The Dark"
https://www.youtube.com/watch?v=KPb20fK0R94
We picked the pots up from Home Depot yesterday, and as they had been rained on in the outdoor garden department, they needed to thoroughly dry before I attempted to paint them. So in the shop they went, unfortunately that takes up a LOT of room...
Another project I had, and this one was more time pressing, was to size up some replacement steel rods for my E-Z Up 13 x 13 Pagoda Gazebo Canopy.
The Auto Show is coming up, and my brother in laws body shop is setting up a booth, and he was going to borrow up the Pagoda to use in the booth, which is great, but unfortunately the last time my wife and I took it to the beach, we got run off the beach by some fast severe weather, and I forgot the extension rods that hold the what would be the eaves if this were a normal structure, out away from the verticals.
So I sized up the bores for the rods, and found that they are 1/2", I used some 1/2" hardwood dowel from the craft store to size up how long the rods should be. I talked with the support folks at EZ-Up, they would be more than happy to sell me replacements for $25.00 + S&H by the way... but they couldn't tell me for sure the length, apparently there are 2 different sizes, mine happened to be the 28", so...
Once the lengths were measured, the angle grinder with the HF metal cutoff wheel was brought out, and the rods were cut, the rough edges were dressed off by hand with a file, and the rods were thoroughly cleaned...
For the Auto Show. I won't bother with paint on the rod yet... But once I get done with that, I get the rods back to the shop, they will get thoroughly cleaned, roughed up with some sandpaper, and then primed, and painted. Mostly to keep rust away from the canopy fabric... The end that goes into the fabric pockets are going to be dipped in Plasti-Dip to finish the job up...
Now as promised in the title... I managed to stumble across a Youtube Channel courtesy of none other than Wil Wheaton, yes, I am that geeky that I follow Wil's blog, and have him in my Google+ circles, and controversial or not, I actually LIKED the Wesley Crusher character in Star Trek The Next Generation! but I digress...
Being a child of the 1980s, heavy metal was a staple of the music scene when I was a teen, and of course, as I ripen, uh I mean mature into the graceful (yeah right) age I am now... I find my musical taste varies quiet a bit more, and I appreciate the finer points of true art that I simply wasn't open to at a younger age. Combine that with far too many years with my fall seasons spent at the Renaissance Faire, and yes... I think I have acquired a fondness for the more obscure musical genres...
So without further Adieu, I present to you 2 classically trained harpists Camille and Kennerly with their cover of Iron Maidens "Fear Of The Dark"
https://www.youtube.com/watch?v=KPb20fK0R94
17 June, 2014
Fixing The Flexy Flares...
In an attempt to keep rocks, mud, sand, and whatnot from being flung up at the paint on the truck quite so much by the 12.5" wide mud tires I needed a wider than typical fender flare for my 2004 Ford F150. And while I know there are plenty of folks that like them, but I personally don't care for the looks of the big chunky flares like the Bushwackers. After more than a little research I went seriously old school and opted for a set of cut to fit Pacer Performance Flexy Flares. Basically a 2.5" rubber fender flare that attaches to the inside lip of the fender opening.
Now these are really, painfully simple fender flares, akin to what you see on school busses, ambulances, and fender chopped 4x4s world wide... These have been available and in use literally for decades. I remember a guy in high school that had a set of the universal fit (you cut them to match your application) on a 1965 Corvair. Well anyway I digress...
Due to some vandalism damage my truck had to spend some quality time in the body shop at Cook Ford in Texas City Texas, and I should mention here and now, and mind you, I am a very forgiving customer knowing full well people make mistakes, and I don't take making this recommendation lightly in the slightest, but I have to say, in the strongest terms, DO NOT DO BUSINESS WITH COOK FORD! I took my truck there as they were the closest Ford dealer that was in my insurance companies preferred repair facility program. If I have anything to say about it, they won't be for much longer. But don't take my word for it, take a look at their BBB rating. I dropped the truck off on Thursday before Memorial Day weekend, and was told that they would not be able to even take a look at it until the following Tuesday, so I went ahead and left the truck there. I left with a leery feeling of this shop, and started digging into the reviews and BBB complaints, and by Friday morning I got up early and got to the body shop just after opening time. Unfortunately the insurance company had already notified them that I wanted to get my truck out of there, and they had already started pulling the truck apart, and had sanded the fender down and had bondo on it. So I was kind of stuck... End result?They botched the repair job badly, took it in to straighten some fender damage caused by vandalism, they delivered it with the fender STILL bent, proud of the door by no less than 3mm and distinctly bowed out at the wheel opening like it was a wide body kit, fender bottom edge trim wouldn't fit door trim they took off for painting they bent in the process, and the windshield glass I specifically asked the body shop manager, Sonia I think her name was, some blonde woman is all I am sure of, if they were going to use the OEM glass with the F150 logo, ended up being a generic aftermarket piece, so she flat out LIED to my wife and myself.
Anyway, among the other things that were done wrong such as the fender that was supposed to be straightened, wasn't delivered straight, I also found the fender flare on the other side of the truck had several of the screws removed. This was causing the flare to curl in, and contact the tire during turns.
I opted for a more permanent fix than a replacement screw however, and broke out the Harbor Freight rivet gun. The hole was already in the flare, and in the fender, all I had to do was run the rivet through both holes, put the riveter on the stud and pull the handle.
The end result is that the fender flare trailing edge is now tight up against the fender, MUCH tighter than was possible with the screw. I am actually considering pulling the existing screws, one at a time, making any width adjustments needed, and running rivets in instead of screws.
Tire to fender flare rub now gone, I can now go to a Chevrolet dealer (that just seems existentially wrong) to get the proper repair done. They had an '09 FX4 F150 in black that they were prepping for delivery that just came out of the shop with similar damage, and not a hint of the problems I had... Hopefully they get the job done smoothly, and this can be the end of my fender mash nightmare...
Likewise, not with any of my rigs, but a friend of ours, who happens to do housekeeping work for us (she helps us catch up every other week with stuff we can't finish off), needed help with her little truck. The bracket that holds the gas strut for the camper shell hatch lost the rivets that hold it on, so I re-riveted that, and double checked the other side...
Overall, the HF riveter that I picked up specifically for this purpose, I used to have a Stanley years ago but it grew feet and left me years ago, anyway, the HF riveter seems fairly well made, it does what it is supposed to, how it is supposed to, and doesn't seem like it should have any failure due to skimped materials or construction methods, however it was supposed to come with a spanner to help change the tips, mine did not, I considered taking it back, but I have more than enough wrenches and don't really need it... Oh for what it's worth, the units in the store have yellow handles, not red, and the metal frame black part is smooth either painted or powder coated, not sure, but it isn't the hammered finish shown in the HF pics...
Now these are really, painfully simple fender flares, akin to what you see on school busses, ambulances, and fender chopped 4x4s world wide... These have been available and in use literally for decades. I remember a guy in high school that had a set of the universal fit (you cut them to match your application) on a 1965 Corvair. Well anyway I digress...
Due to some vandalism damage my truck had to spend some quality time in the body shop at Cook Ford in Texas City Texas, and I should mention here and now, and mind you, I am a very forgiving customer knowing full well people make mistakes, and I don't take making this recommendation lightly in the slightest, but I have to say, in the strongest terms, DO NOT DO BUSINESS WITH COOK FORD! I took my truck there as they were the closest Ford dealer that was in my insurance companies preferred repair facility program. If I have anything to say about it, they won't be for much longer. But don't take my word for it, take a look at their BBB rating. I dropped the truck off on Thursday before Memorial Day weekend, and was told that they would not be able to even take a look at it until the following Tuesday, so I went ahead and left the truck there. I left with a leery feeling of this shop, and started digging into the reviews and BBB complaints, and by Friday morning I got up early and got to the body shop just after opening time. Unfortunately the insurance company had already notified them that I wanted to get my truck out of there, and they had already started pulling the truck apart, and had sanded the fender down and had bondo on it. So I was kind of stuck... End result?They botched the repair job badly, took it in to straighten some fender damage caused by vandalism, they delivered it with the fender STILL bent, proud of the door by no less than 3mm and distinctly bowed out at the wheel opening like it was a wide body kit, fender bottom edge trim wouldn't fit door trim they took off for painting they bent in the process, and the windshield glass I specifically asked the body shop manager, Sonia I think her name was, some blonde woman is all I am sure of, if they were going to use the OEM glass with the F150 logo, ended up being a generic aftermarket piece, so she flat out LIED to my wife and myself.
Anyway, among the other things that were done wrong such as the fender that was supposed to be straightened, wasn't delivered straight, I also found the fender flare on the other side of the truck had several of the screws removed. This was causing the flare to curl in, and contact the tire during turns.
I opted for a more permanent fix than a replacement screw however, and broke out the Harbor Freight rivet gun. The hole was already in the flare, and in the fender, all I had to do was run the rivet through both holes, put the riveter on the stud and pull the handle.
The end result is that the fender flare trailing edge is now tight up against the fender, MUCH tighter than was possible with the screw. I am actually considering pulling the existing screws, one at a time, making any width adjustments needed, and running rivets in instead of screws.
Tire to fender flare rub now gone, I can now go to a Chevrolet dealer (that just seems existentially wrong) to get the proper repair done. They had an '09 FX4 F150 in black that they were prepping for delivery that just came out of the shop with similar damage, and not a hint of the problems I had... Hopefully they get the job done smoothly, and this can be the end of my fender mash nightmare...
Likewise, not with any of my rigs, but a friend of ours, who happens to do housekeeping work for us (she helps us catch up every other week with stuff we can't finish off), needed help with her little truck. The bracket that holds the gas strut for the camper shell hatch lost the rivets that hold it on, so I re-riveted that, and double checked the other side...
Overall, the HF riveter that I picked up specifically for this purpose, I used to have a Stanley years ago but it grew feet and left me years ago, anyway, the HF riveter seems fairly well made, it does what it is supposed to, how it is supposed to, and doesn't seem like it should have any failure due to skimped materials or construction methods, however it was supposed to come with a spanner to help change the tips, mine did not, I considered taking it back, but I have more than enough wrenches and don't really need it... Oh for what it's worth, the units in the store have yellow handles, not red, and the metal frame black part is smooth either painted or powder coated, not sure, but it isn't the hammered finish shown in the HF pics...
13 June, 2014
How to deal with a jointer that is too narrow.
I am doing some stock preparation of some pretty rough walnut that I picked up off of Craigslist a few years ago. Much of the stock is 8" or wider, and just under 4/4.
Now if you have been paying attention to my blog, and have gone through the shop tour page, you will remember that I have and use a 6-1/8" bench top jointer. Nice, space saving contraption, that is all but useless for face jointing wider stock. I pretty much MUST keep my stock under 6" wide or it's a no go for this little guy...
To solve the problem I resort to the time tested method of all sorts of woodworkers. I built a jig. Well built might be an overstatement...
Simply put, I used a planer jointing sled.
Now for those unfamiliar with what a planer jointing sled is, it is a piece of dead flat stock, in this case 3/4" plywood, that is 8' long, and just barely narrower than the max capacity of the planer. In my case I have a 13" planer, so the jointing sled is 12-7/8". Thus my stock handling limitation here is 8' x 12.75". You need just enough space around the workpiece to be able to secure it to the sled...
The work piece itself, is secured to the sled via a hot glue gun and glue. Using the same techniques as you would with a jointer to determine which face to start with, secure your work piece to the sled, building up the hot glue to make up gaps between sled and work piece at the edge. The idea here is to solidly hold the work piece, and keep it flat as you plane away at it... In my case, I had approx 1/16" twist over 6' of stock, so I had a corner that was proud of the rest of the stock..
Run your stock, with the sled through as you would normal stock, until you have the exposed surface dead flat. If your planer snipes, it will be a bit exaggerated on a sled, BUT depending on how much material you are taking off, that can be dealt with...
Once the exposed side is flat, just cut the hot glue free, and remove the work piece from the sled. Clean up the sled and set it aside, then process the other side until you get to your final thickness...
With your stock flat, and at your desired width, edge joint it, just like with face jointing, you have multiple options, but in general, unless you are jointing monster sized stock, even a tiny 4" bench top jointer should suffice... I have read on most forums guys trying to say that a bench top jointer can't get a straight edge on anything longer than about 36", I have found that to be pure bovine fertilizer.
I have seen time and again forum members advising newbies to spend the money and buy a jointer first before a planer, the process I just described above to you, along with a similar, and similarly simple table saw edge jointing sled, make me seriously question the wisdom of that advise. If you don't have the budget, or space for a jointer, AND a planer, you are FAR better off with just a planer, and alternative planing methods.
If you would like more detailed information about alternative jointing methods, take a look at Marc Spagnulo A.K.A. "The Wood Whisperer"s video called "The Jointers Jumpin'" http://youtu.be/M-ZZ0dhbJYY . He covers areas that many folks simply don't think about, and unlike certain TV personalities, he takes time to SHOW you how it's done!
Now if you have been paying attention to my blog, and have gone through the shop tour page, you will remember that I have and use a 6-1/8" bench top jointer. Nice, space saving contraption, that is all but useless for face jointing wider stock. I pretty much MUST keep my stock under 6" wide or it's a no go for this little guy...
To solve the problem I resort to the time tested method of all sorts of woodworkers. I built a jig. Well built might be an overstatement...
Simply put, I used a planer jointing sled.
Now for those unfamiliar with what a planer jointing sled is, it is a piece of dead flat stock, in this case 3/4" plywood, that is 8' long, and just barely narrower than the max capacity of the planer. In my case I have a 13" planer, so the jointing sled is 12-7/8". Thus my stock handling limitation here is 8' x 12.75". You need just enough space around the workpiece to be able to secure it to the sled...
The work piece itself, is secured to the sled via a hot glue gun and glue. Using the same techniques as you would with a jointer to determine which face to start with, secure your work piece to the sled, building up the hot glue to make up gaps between sled and work piece at the edge. The idea here is to solidly hold the work piece, and keep it flat as you plane away at it... In my case, I had approx 1/16" twist over 6' of stock, so I had a corner that was proud of the rest of the stock..
Run your stock, with the sled through as you would normal stock, until you have the exposed surface dead flat. If your planer snipes, it will be a bit exaggerated on a sled, BUT depending on how much material you are taking off, that can be dealt with...
Once the exposed side is flat, just cut the hot glue free, and remove the work piece from the sled. Clean up the sled and set it aside, then process the other side until you get to your final thickness...
With your stock flat, and at your desired width, edge joint it, just like with face jointing, you have multiple options, but in general, unless you are jointing monster sized stock, even a tiny 4" bench top jointer should suffice... I have read on most forums guys trying to say that a bench top jointer can't get a straight edge on anything longer than about 36", I have found that to be pure bovine fertilizer.
I have seen time and again forum members advising newbies to spend the money and buy a jointer first before a planer, the process I just described above to you, along with a similar, and similarly simple table saw edge jointing sled, make me seriously question the wisdom of that advise. If you don't have the budget, or space for a jointer, AND a planer, you are FAR better off with just a planer, and alternative planing methods.
If you would like more detailed information about alternative jointing methods, take a look at Marc Spagnulo A.K.A. "The Wood Whisperer"s video called "The Jointers Jumpin'" http://youtu.be/M-ZZ0dhbJYY . He covers areas that many folks simply don't think about, and unlike certain TV personalities, he takes time to SHOW you how it's done!
08 June, 2014
Follow up update... Dealing with the pressure!
Good morning all, just a quick post between Sunday morning activities...
Upon waking up and prior to heading out this morning, I popped out to the shop to take a quick peek at the pressure gauges. Sure enough the system is holding steady.
I have some long term durability concerns for using the rubber hoses, however I realize that I am pretty much going to require hoses to connect the compressors to the manifolds at least as the compressors vibrate and I need the flexible connection to keep from transferring the vibration to the rest of the plumbing, and in turn to the wall studs, and the rest of the house...
My options as I see them are...
#1. accept the fact that the rubber hoses will eventually spring leaks and fail (they all do) and replace them on an as needed basis.
#2. Upgrade the output side of the system between the filtration system and the hose reel adding possibly a hard drop at the front of the shop using a snap together system such as Rapidair.
#3. Run a system similarly laid out to the rapidair mentioned above, but with sweat fit / soldered copper pipe.
#4. Same as the 2 above, but using black iron...
I know I am overthinking this at this point, as it is all set up and working so well, but I want to have my head around any future possibilities.
Upon waking up and prior to heading out this morning, I popped out to the shop to take a quick peek at the pressure gauges. Sure enough the system is holding steady.
I have some long term durability concerns for using the rubber hoses, however I realize that I am pretty much going to require hoses to connect the compressors to the manifolds at least as the compressors vibrate and I need the flexible connection to keep from transferring the vibration to the rest of the plumbing, and in turn to the wall studs, and the rest of the house...
My options as I see them are...
#1. accept the fact that the rubber hoses will eventually spring leaks and fail (they all do) and replace them on an as needed basis.
#2. Upgrade the output side of the system between the filtration system and the hose reel adding possibly a hard drop at the front of the shop using a snap together system such as Rapidair.
#3. Run a system similarly laid out to the rapidair mentioned above, but with sweat fit / soldered copper pipe.
#4. Same as the 2 above, but using black iron...
I know I am overthinking this at this point, as it is all set up and working so well, but I want to have my head around any future possibilities.
06 June, 2014
Clearing the air
With the compressed air system fully sealed and holding pressure I am turning my attention to insure the air supplied particularly to spray guns is uncontaminated... The primary filter does a decent job but I wanted to insure dryer air and no oil passing through.
So I have gone ahead, bit the bullet as it were, and coughed up the bucks to get the Desiccant Dryer / Oil Removal Filter unit, and an FRL (Filter / Regulator / Lubricator) connector bracket from Harbor Freight. While they are still in the packaging, I am starting to wonder if Harbor Freight is trying to position themselves up a step or two on the tool quality ladder...
I am going to say this loud and proud, and will probably catch a ton of flack for it, but after my experiences with the wide variety of tools I have used, At this point I would happily cough out funds for HF tools long before I give Black and Decker or Skil a penny... I am noticing the tools I get from HF are higher quality than those better known name brands which has me wondering if Harbor Freight is going to follow by climbing the price tag ladder soon too...
I am going to say this loud and proud, and will probably catch a ton of flack for it, but after my experiences with the wide variety of tools I have used, At this point I would happily cough out funds for HF tools long before I give Black and Decker or Skil a penny... I am noticing the tools I get from HF are higher quality than those better known name brands which has me wondering if Harbor Freight is going to follow by climbing the price tag ladder soon too...
So I started out with the regulator / filter already installed... That needed to be disconnected, bled down and removed from the wall. I have removed the L bracket from the regulator body as well. The FRL bracket I will talk about in a minute gives me great solid mounting options.
Add to that the Desiccant Dryer / Oil Removal Filter that I have on hand...
And the FRL connector bracket... Mind you, I could have just as easily gone with a 3/8" close nipple and connected them together, but I wanted even, consistent mounting brackets across the devices, so I spent the extra $2.00 and got this thing... It will give me a nice clean install and should actually look like the manufacturer intended for all of this to be together...
While I was ready to go, documentation on configuration is kind of lacking, so I needed to make a decision on to mount the dryer / filter before, or after the regulator. I am opting for after so that the flow goes from compressors --> manifold --> regulator / filter --> desiccant dryer / oil removal filter assembly --> output manifold --> hose reel...
The steps I used to install and test were....
- Depressurize and bleed off existing system.
- Remove the existing regulator / filter from the wall.
- Prep wall mount board (already cut to desired size, simply pre drill counter sunk mounting holes and mount to wall).
- Remove the nipple and manifold from the outlet side of the regulator.
- Thoroughly clean all mating surfaces of outlet including female threads.
- Prep the dryer by installing desiccant beads.
- Assemble the bracket to the regulator and the dryer / oil removal filter.
- Reapply pipe thread compound to the male threads on the nipple / manifold assembly and assemble that into the outlet of the dryer / oil removal filter.
- Mount assembly onto mount board and reconnect inlet and outlet hoses.
- Pressurize and test for leaks.
I do feel I need to address those that are pooh poohing this rig for lack of lubricant in the air stream. Well that is the whole point! I have for literally decades, used lubricated air tools on pnuematic systems without lubricators, and with filters. You simply need to add some air tool oil to the inlet at the outset of each days work and periodically through the day...
The installation, particularly of the FRL connector was not documented at all and wasn't completely obvious and not everything was machined to fit nicely. Specifically the regulator / filter body niche for the bracket wasn't milled out entirely far enough, and I had to finesse with a fine file. I opted to file a shave off of the ear of the connector bracket though, easier to get to cleanly...
The installation, particularly of the FRL connector was not documented at all and wasn't completely obvious and not everything was machined to fit nicely. Specifically the regulator / filter body niche for the bracket wasn't milled out entirely far enough, and I had to finesse with a fine file. I opted to file a shave off of the ear of the connector bracket though, easier to get to cleanly...
Of course I also addressed swapping out the flaky Husky regulator on my HF 8 gallon compressor. I sourced up a replacement regulator for the HF from HF... Go figure right? Although the gauge ranges higher than the stocker, this regulator appears otherwise identical to the unit the small compressor was outfitted with from the factory. Should be a good clean install. When assembled and pressurized, the gauge still didn't go up to 125 PSI, and shockingly, I had been making a mistake. My small compressor is the 115 PSI not 125 PSI model! No harm no foul on the Husky regulator though, It wouldn't show anything over 100PSI, and the gauge would swing from 80 to 100 all day long... It HAD to go...The Central Pnuematic piece build quality wise is yet another example of HF beating the competition quality and cost wise!
Once all of these were assembled, pressurized, and adjusted, I ran bubble tests against the joints, addressed any and all leaks, and there were a few, most notably the clear cap for the filter fail indicator on the oil removal filter, and I had to fiddle with the bracket to stop the leaks there, and then ran a leak down test. Keeping them pressurized but off overnight, and both compressors are holding pressure with no drop. Looking good!
***UPDATE***
I should have posted these earlier, but here is the photo of the completed rig... The regulator / filter has a clean factory assembled look when joined to the dryer / oil removal filter.
In order from left to right, in to out. couplers, check valves, reducer nipples, tee, nipple, regulator / filter, FRL coupler, oil removal filter, FRL coupler, desiccant dryer, nipple, tee, reducer nipples, couplers. The plastic bulb thing on top where the filter replacement indicator on the oil removal filter is where my leak was when I assembled this. I loosened it up and straightened the O ring, then ran it back in carefully using a 19 MM deep well socket.
The mount board is a simple piece of scrap 3/4" ply screwed directly to the studs, and then the FRL couplers screwed to it using 1-5/8" drywall screws.
And after 26 hours turned off but kept pressurized, the in tank pressure is exactly where it was when I threw the switch to the off position. On the 29 gallon unit mind you, I didn't check the 8 gallon...
Yeah, I am LOVING that picture...
I should have posted these earlier, but here is the photo of the completed rig... The regulator / filter has a clean factory assembled look when joined to the dryer / oil removal filter.
In order from left to right, in to out. couplers, check valves, reducer nipples, tee, nipple, regulator / filter, FRL coupler, oil removal filter, FRL coupler, desiccant dryer, nipple, tee, reducer nipples, couplers. The plastic bulb thing on top where the filter replacement indicator on the oil removal filter is where my leak was when I assembled this. I loosened it up and straightened the O ring, then ran it back in carefully using a 19 MM deep well socket.
The mount board is a simple piece of scrap 3/4" ply screwed directly to the studs, and then the FRL couplers screwed to it using 1-5/8" drywall screws.
And after 26 hours turned off but kept pressurized, the in tank pressure is exactly where it was when I threw the switch to the off position. On the 29 gallon unit mind you, I didn't check the 8 gallon...
Yeah, I am LOVING that picture...
